| M34 | |
|---|---|
| Maximum vertical reach | 34.0m |
| Maximum gross horizontal reach | 30.0m |
| Maximum net horizontal reach | 27.7m |
| Reach depth | 23.2m |
| Minimum unfolding height | 7.8m |
| Number of arms | 4 |
| Pipeline diameter | 125mm |
| Pump length | 10.7m |
| Front outrigger spread | 6.2m |
| (4.2m OSS) | |
| Rear outrigger spread | 4.8m |
